Deploying Grafana to Azure Web Apps for Container and Azure Storage - File Share for storage.

Hello Cloud adventurers, I have been on a learning journey this year with containerization, specifically docker. Continuing the series of blogs, I wanted to try deploying Grafana to Azure but as a docker container. I know there are different ways and different services within Azure that you can use to deploy a container, but I will be using Azure Web Apps.

Deploying Grafana to Azure’s Web Apps for Containers is a straightforward process:

  • A storage account

  • An Azure Files share

  • Initiate an empty Sqlite database

  • Web Apps for Containers Azure App Service

  • Mount the Azure Files share

  • Set an environment variable

Let’s get started.

Create a Storage Account

Begin by creating an Azure Storage account. This is where we will create the File Share later. You might ask, why do we need a File Share?

If I deployed Grafana as a container, the Sqlite database (and plug-ins) would be lost as soon as the container is reset. Hence, we will be using the File Share as storage for our Grafana database.

I have created grafana-rg as the resource group where all the resources will be deployed for this blog post. For the Storage Account, make sure you use a unique name and I went with Standard performance with Geo-Redundant Storage (GRS). I left everything else as default.

Creating a Storage Account in Azure

Create an Azure Files Share

Navigate to your newly created storage account and scroll down to File Shares.

Azure Storage Account with File Shares highlighted on the Configuration Blade.

Click on the + File share button.

For the Name, I chose grafana-storage you can choose whatever you like. I went with the Transaction optimized tier. Everything else was left to default.

Creating new File Share with Transaction optimized Tier

Initiate an empty Sqlite database

I found it the hard way that if we leave Grafana to create the database, it will run into a database lock error. To overcome this, we’re going to create a Sqlite database manually and then, using the Azure CLI, we will upload the database to the file share.

On a Windows machine, you can run the following commands.

Provided you’ve already installed choco.

If you are on macOS, Sqlite is already installed and, therefore, you can skip the first command.

Also, you’ll need Azure CLI installed and authenticated with your Azure account.

choco install sqlite
sqlite3 grafana.db 'PRAGMA journal_mode=wal;'

Now, let's copy the grafana.db to our File Share. We will use the azcopy command.

az login az storage copy -s .\grafana.db -d https://<storage_account><file_share> --subscription <subscription_name>

Replace <storage_account>, <file_share>, and <subscription_name>, with the appropriate values: the name of your storage account, the name of your file share and your subscription’s id or name.

AZ Copy command output, copied the grafana.db over to Azure File Share

App Service

Create a new Azure web application that publishes a Docker Container and choose Linux for the OS. Choose a pre-existing Linux App Service Plan or create a new one.

There is a Free F1 Plan, but I went with Basic B1.

Creating a Web App, first settings page with Docker Container and Pricing plan as Basic B1.

For the Docker options, we’re going to leave the defaults for the moment. We’ll update this later once we have our environment fully configured. All other options we will the default.

Make sure the Enable Public Access is checked.

Using the default settings for Web App Container under Docker tab

Once the Azure Web App has been successfully configured, you can access it by the app service URL. You should see the nginx message.

Azure Web App page with Default Domain and Configuration highlighted

Now we will configure the Web App container to use the Azure File Share as storage.

Mount the Azure Files share

In the Azure portal, on the App Service’s blade, click on Configuration, then Path mappings.

Azure Web App Configuration window, with Path mappings highlighted

Now click on + New Azure Storage Mount.

Azure Web App configuration: adding New Azure Storage Mount

Name the storage mount whatever you’d prefer and choose the Storage Account you created before, Azure Files for Storage Type, and the Azure File share created before for the Storage Container. Finally, most important, for the Mount path, type in /var/lib/grafana.

New Azure Storage Mount for Azure Web App with all the parameters filled in

Click OK then Save at the top.

We just attached our Azure File share to our container and it will be mounted at /var/lib/grafana which is Grafana’s default file path for the database and its plugins. This means, should our container be restarted for any reason, none of our settings will be lost.

Set an Environment Variable

Now we have Grafana storing the database in our /var/lib/grafana mount path. However, it will not use the PRAGMA flag that we used earlier, therefore, we will experience database locking.

Grafana allows us to overwrite default configuration variables by leveraging environment variables. So, we’re going to use Grafana’s default database connection string, but append the necessary flag.

Click on the Configuration blade once again for your Web App(you should still be on the Configuration blade from the previous step).

Now, choose Application settings and add a + New application setting.

Azure Web App Configuration page with Application Settings highlighted

For the setting, enter the following:

Value: sqlite3:///var/lib/grafana/grafana.db?cache=private&mode=rwc&_journal_mode=WAL

Leave the Deployment slot setting unchecked.

Adding new application setting for Azure Web App

Make sure you click Save.

Azure Web App Configuration page with Save button highlighted

Awesome, now we have the environment configured, but we need to update our container’s image source.

In the App Service blade, under Deployment Center, choose Settings.

Azure Web App Deployment Center page: changing the container settings

By default, the Full Image Name and Tag will be set to nginx(which was set when we created the App Service).

We want to use the Grafana Container Image, I have my own docker image for Grafana that I want to use, but you can use the default one that is provided by Grafana.

Curious on how to create your own Docker image, watch this video on how I did it.

Docker Hub with my own grafana-container image

Change the registry source to Docker Hub, and the image to grafana/grafana if you want to use the official Grafana Image.

Click Save.

Azure Web App Deployment Center Container settings filled in with appropriate values for my grafana image

It may take a moment for Azure to pick up the changes once you submit them. You can click Refresh a few times and check the logs to ensure the container was deployed correctly.

Azure Web App portal with Refresh and Logs button highlighted

Now let's visit the Web App URL to see the changes.

Grafana Login screen when accessing the Azure Web App URL


We did it! We now have Grafana deployed to Azure Web Apps for Containers with Azure File Share as storage, making it redundant, not prone to losing data on container restarts and the ability to scale to support the necessary load.
